Number of Channels:16

I/O Configuration:2 Groups of 8

On-State Voltage:10 – 30 VDC

On-State Current:0.5 A

Voltage Rating:24 VDC

Current Rating:Module: 4 A, Surge: 1 A

Isolation Rating:500 VAC

Enclosure Type:IP20, Open Type

Communication Protocol:DeviceNet

Mounting Method:DIN Rail, Panel

Length:1.9 IN

Width:1-1/2 IN

Height:4.4 IN

Temperature Range:0 – 60 DEG C

Operating Environmental Conditions:Non-Operating Temperature: -40

    The Allen-Bradley 1790D-T16BV0 Compact Block IO Module is specifically engineered for high-performance applications requiring precise and efficient data exchange in a compact design. This module offers a versatile platform for integrating with existing industrial networks, enhancing system reliability and reducing installation complexity.

    Featuring a robust isolation rating of 500 VAC, the 1790D-T16BV0 ensures reliable operation even under harsh environmental conditions, making it ideal for diverse industrial settings. Its open-type enclosure facilitates easy access for maintenance without compromising on protection against dust and water ingress.

    With support for DeviceNet communication protocol, this module seamlessly connects to Allen-Bradley and third-party devices, enabling streamlined integration into complex automation systems. The inclusion of both DIN rail and panel mounting options ensures flexibility in installation scenarios, catering to a wide range of industrial environments.

    Equipped with a comprehensive set of specifications including up to 16 I/O channels in two groups of eight, this module caters to various control requirements, from simple monitoring tasks to complex data processing operations. Its high current rating of 4 A per channel ensures sufficient power delivery for demanding applications, while the surge current capability provides protection against transient voltage spikes.

    The Allen-Bradley 1790D-T16BV0 Compact Block IO Module is designed with durability and reliability in mind, offering a temperature range of 0 to 60 degrees Celsius, ensuring operational stability across a wide spectrum of industrial climates. Whether you’re looking to upgrade existing systems or build new ones, this module delivers the performance and versatility needed for today’s dynamic industrial automation needs.
